This advanced mesh system is engineered for large homes, ensuring smooth, uninterrupted performance for 4K streaming, gaming, and more.

Key Features:

• High-Speed Performance
  • Supports internet speeds up to 1000 Mbps for seamless browsing and streaming.
• 4-Stream Dual-Band Technology
  • Offers 1201 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band.
• Mesh Network Support
  • Auto-sync multiple units for expanded coverage with no dead zones.
• Gigabit Ethernet Ports
  • Two ports for ultra-fast wired connections.
• Smart Functionality
  • Includes fast roaming, VPN server/client support, and Cudy Mesh compatibility.
• Easy Installation
  • User-friendly setup for hassle-free operation.

The CUDY AX1800 M1800 Pack-1 Router combines speed, coverage, and versatility, making it a perfect solution for modern households seeking reliable connectivity.

Cudy App

Hardware Specs

Model Version	M1800 2.0
CPU	Chipset	MT7621
	CPU Details	880 MHz Dual-Core, MIPS1004Kc
Memory/Storage	Flash/ROM	16 MB (128 Mbit) NOR
	DDR/RAM	256 MB (2 Gbit) DDR3
Wireless	5 GHz Wi-Fi Speed	1201 Mbps
	2.4 GHz Wi-Fi Speed	574 Mbps
	5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	Wi-Fi Antennas	4× Internal
	5 GHz Antenna Gain Max	6.04dBi
	2.4 GHz Antenna Gain Max	4.9dBi
	FEM or PA/LNA	5 GHz: 2× Internal 2.4 GHz: 2× Internal
	Beamforming	True
	Range Performance	Max: 170 m (558 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
	Wall Performance	One wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'')
	Multi-Pack Indoor Coverage	2 Pack: 360 m² (3900 sq ft) 3 Pack: 500 m² (5500 sq ft) Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of two obstacles to each room.
Interfaces	Gigabit RJ45 Ports	2
	Ethernet Notes	Port 1 as default WAN port, both as LAN ports on Mesh satellite units
	LED	System Speed/Link/ACT of Ethernet Port
	Physical Buttons	WPS Button Reset Button
	Power Input	DC Jack
Power	Power Methods	DC
	DC	12V 1A
	Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1A DC
Reliability	Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing
Certifications	FCC, CE
Mechanical	Installation	Desktop
	Dimension	Φ110×154.5 mm Φ4.33×6.08 inches
	Product Weight	358 g (12.63 oz.)
Package Content	M1800 Power Adapter Ethernet Cable Installation Guide
Model Version M1800 2.0 Wireless Wi-Fi Standards Wi-Fi 6 Max Wi-Fi Modulation 1024-QAM Wi-Fi Efficiency OFDMA MU-MIMO BSS Color Max Capacity 256 Recommended Client Upper Limit 100 Max Wi-Fi Channel Width 80 MHz Wi-Fi Security WPA/WPA2/WPA3 Guest Network 2.4 GHz, 5 GHz WPS True General Operation Modes Wi-Fi Router Access Point Range Extender WISP Client Mesh Cudy Mesh Mesh Backhaul Wireless Backhaul Wired Backhaul Multi-Band Backhaul true WAN Mode DHCP Static IP PPPOE Internet Failover Sequence WAN WISP Network QoS Per-User Rate Limiting DHCP Address Reservation DHCP Client List Server IP Versions IPv4/IPv6 IPv6 Protocols Relay Dynamic (SLAAC/DHCPv6) Staic (Fixed IP) Passthrough 464XLAT MAP-E DS-Lite IPTV/VLAN Bridge Tag VLAN TTL Customization Extend Spoof Custom IGMP IGMP Proxy IGMP Snooping Forwarding Port Forwarding Port Triggering UPnP DMZ Firewall SPI Firewall DoS Protection Block PING Application Layer Gateway IPSec Passthrough L2TP Passthrough PPTP Passthrough FTP Passthrough TFTP Passthrough H323 Passthrough SIP Passthrough RTSP Passthrough Utilities VPN Server WireGuard OpenVPN IPsec Zerotier PPTP L2TP VPN Client WireGuard OpenVPN IPsec Zerotier PPTP L2TP DNS Options DNS over TLS Manual DNS Rebind Protection Override Clients' DNS DNS over TLS Providers Cloudflare Google Quad9 Custom Wake on LAN True Online Detection True Management All Devices Management Wi-Fi Time Schedule MAC Filter IP/MAC Binding Per-Devices Management Intenent On/Off VPN On/Off Online Time Schedule Device Rename Content Management Domain Filter IP Filter System LED Control ture Local Control Method Config Web Page App Control Remote Control Method Config Page via HTTPS App Control TR069/TR098/TR111/TR181 Firmware Upgrade Local Update App (Over the Air) Online Update Reliability Timed Reboot Backup and Restore Diagnostic Tools Diagnosis Ping Traceroute NSLookup System Log Languages English Bengali Catalan Czech German Greek Spanish French Hebrew Croatian Hungarian Italian Japanese Khmer Korean Dutch Norwegian Polish Portuguese Romanian Russian Slovak Swedish Thai Turkish Ukrainian Vietnamese Simplified Chinese Traditional Chinese Dashboard Panel Internet Status Mesh Status Devices Management WAN Status LAN Status WISP Status Wi-Fi Status VPN Status DHCP Server Status System Version Charts Mesh Topology Internet Speed WISP Speed Wi-Fi Speed
