Portable Heating Cup 300Ml Jr01

Introduction

The JR01 Portable Smart Baby Bottle Warmer is designed to provide a convenient and safe solution for warming baby milk or water on the go. Featuring an LED display for real-time temperature tracking, rapid warm-up capabilities, and versatile USB Type-C charging, this device ensures your baby's meals are always at the perfect temperature, whether at home or traveling.

This manual provides essential information for the safe and effective use of your JR01 Portable Smart Baby Bottle Warmer. Please read it thoroughly before first use and keep it for future reference.

Safety Information

• Food-Grade Materials: The warmer is constructed with high borosilicate glass (BPA-free) and a 316 SUS stainless steel heating base, ensuring all materials in contact with liquids are safe and toxin-free.
• Keep Dry: Always ensure the control panel is dry before operation. Avoid operating with wet hands.
• No Submersion: Do not submerge the heating base in water or any other liquid to prevent electrical damage and ensure user safety.
• Supervision: Always supervise the device when in use, especially around children.
• Proper Charging: Use only the provided USB cable and compatible power sources (power bank, car adapter, wall charger) for charging.
• Temperature Check: Always check the temperature of the liquid before feeding your baby to prevent burns.

Specifications

Setup

1. Initial Cleaning: Before first use, disassemble the bottle warmer and thoroughly clean all parts that will come into contact with milk or water. The glass body and lid can be washed with warm soapy water. Wipe the heating base with a damp cloth, ensuring no water enters the charging port or control panel.
2. Charging: Connect the provided USB Type-C cable to the charging port on the heating base. Plug the other end into a compatible power source (e.g., power bank, car adapter, wall charger). The LED display will indicate charging status. Ensure the device is fully charged before first use for optimal performance.
3. Assembly: After cleaning and drying, reassemble the bottle warmer. Ensure the silicone sealing ring is properly seated in the lid to prevent leaks. Securely attach the glass body to the heating base.

Operating Instructions

1. Fill the Bottle: Open the lid and pour the desired amount of milk or water into the glass bottle. The bottle has measurement markings for convenience.
2. Secure the Lid: Close the lid securely, ensuring the safety lock is engaged to prevent spills.
3. Power On: Press and hold the power button (usually indicated by a circle with a vertical line) on the control panel to turn on the device. The LED display will light up, showing the current temperature.
4. Set Temperature: Use the '+' and '-' buttons to adjust the target temperature. The adjustable range is 37°C to 55°C (98°F to 131°F). The display will show the set temperature.
5. Heating Process: The warmer will automatically begin heating the liquid to the set temperature. The LED display will show the real-time temperature as it rises. Heating typically takes several minutes depending on the initial liquid temperature and volume.
6. Constant Temperature: Once the target temperature is reached, the device will maintain it for up to 8 hours on a full charge.
7. Dispense: When ready to feed, open the lid and carefully pour the warmed liquid into a baby bottle. Always test the temperature on your wrist before feeding.
8. Power Off: After use, press and hold the power button to turn off the device.

Cleaning and Maintenance

Regular cleaning is crucial for hygiene and prolonging the life of your bottle warmer.

1. Disassembly: Ensure the device is turned off and unplugged. Carefully separate the glass body from the heating base. Remove the lid and silicone sealing ring.
2. Cleaning the Glass Body and Lid: Wash the high borosilicate glass body, lid, and silicone sealing ring with warm water and mild, baby-safe dish soap. Use a soft brush if necessary to remove any residue. Rinse thoroughly to ensure no soap remains.
3. Cleaning the Heating Base: Wipe the exterior of the heating base with a soft, damp cloth. Do NOT immerse the heating base in water or rinse it under running water. Ensure the Type-C charging port and control panel remain dry.
4. Drying: Allow all parts to air dry completely before reassembling or storing.
5. Storage: Store the clean and dry bottle warmer in a cool, dry place away from direct sunlight.

Troubleshooting

User Tips

• Versatile Use: The JR01 Portable Smart Baby Bottle Warmer is suitable for warming both breast milk and formula/water. Its adjustable temperature range allows you to select the ideal warmth for your baby's needs.
• Nighttime Convenience: With its 8-hour constant temperature feature, you can prepare the bottle before bed and have warm milk ready for night feedings without leaving your room.
• Travel Essential: Its compact and lightweight design makes it perfect for travel. Easily pack it in a diaper bag or luggage for outdoor excursions or trips.
• Multi-purpose: Beyond baby feeding, this warmer can be used for keeping warm drinks for adults, such as tea or coffee, making it a versatile item for the whole family.
