Lian-Li O11D Distro-Plate G1 G89.O11D-Dpg1

Precision-designed by EKWB for advanced water-cooling performance and stunning aesthetics. Whether you're building a high-performance gaming rig or a showpiece workstation, this distro plate delivers unmatched efficiency and style for O11D and O11D XL cases.

✨ Key Features:

• 🧊 Versatile Cooling Configuration
  Multiple inlet/outlet ports support single/dual GPU setups, vertical GPU mount, and single/dual radiator configurations.

• 🌈 Integrated ARGB Lighting
  Customize lighting with the 5V ARGB header via motherboard sync for a vibrant, personalized build.

• 🚀 High-Performance DDC 3.1 PWM Pump
  Delivers a powerful 500 L/h flow rate with 2.6m pressure head for optimal coolant circulation.

• 🛠️ Seamless Case Compatibility
  Tailored for O11D and O11D XL cases to ensure a clean, precise fit with effortless installation.

• 🧱 Durable, Premium Build
  Designed by EK for reliability and aesthetic appeal with robust materials and a refined finish.

• The LIAN-LI O11D DISTRO-PLATE G1 (G89.O11D-DPG1) is the ultimate choice for water-cooling enthusiasts seeking performance and visual excellence. With premium components, customizable lighting, and advanced cooling capabilities, it’s the centerpiece your build deserves.

O11D Distro Plate G1

Designed by EK. Together we empower you to showcase your water-cooling skills. Multiple inlet and outlet ports. Provide an adaptable solution for single GPU, dual GPU,verticla GPU, single rad or dual rad configuration. ARGB in the front, take full control of the lighting by connecting the 5V header into the motherboard.

Category: CoolingTags: ARGB, cooling, dual GPU, O11D, O11D DISTRO-PLATE G, O11D XL, single GPU, verticla GPU

O11D DISTRO-PLATE G1

PREMIUM WATER-COOLING SOLUTION

DESIGNED BY EK
TOGETHER WE EMPOWER YOU TO SHOWCASE YOUR WATER-COOLING SKILLS

MULTIPLE INLET AND OUTLET PORTS
PROVIDE AN ADAPTABLE SOLUTION FOR SINGLE GPU, DUAL GPU, VERTICAL GPU, SINGLE RAD OR DUAL RAD CONFIGURATION

ARGB IN THE FRONT
TAKE FULL CONTROL OF THE LIGHTING BY CONNECTING THE 5V HEADER INTO THE MOTHERBOARD

COMPATIBLE WITH O11D, O11D XL

ADJUSTABLE TO CATER TO YOUR PC CONFIGURATION

DDC 3.1 PWM WATER PUMP
Maximum Flow: 500 L/h
Maximum Pressure Head: 2.6m
RPM Range: 720~3600 RPM ±10%

DOWNLOAD

O11D-G1-MANUAL

SPECIFICATIONS

MODEL	LIAN LI O11D DISTRO-PLATE G1 DESIGNED BY EKWB WITH DDC 3.1 PUMP
DIMENSIONS	(L) 345 x (W) 131 x (H) 29 mm
MATERIAL	ACRYLIC (BODY) PPS-GF30, EPDM O-RINGS, ALUMINUM OXIDE, GRAPHITE (PUMP)
COMPATIBILITY	O11D, O11D XL
ADDRESSABLE RGB LED STRIP	1 (LED COUNT 18
LED POWER CONSUMPTION	0,3A 5V
CPU BLOCK SUPPORT	1 CPU block
GPU BLOCK SUPPORT	UP TO 2 GPU BLOCKS IN SLOT 1 OR SLOT 2
RADIATOR SUPPORT	UP TO 2 X 120/240/360MM RADIATORS UP TO 60MM IN THICKNESS
PORT THREAD TYPE	G1/4
MOUNTING HOLE SIZE	M4 (MOUNTING HARDWARE IS INCLUDED)
PUMP ELECTRICAL & MECHANICAL PROPERTIES
MOTOR	ELECTRONICALLY COMMUTED MOTOR
RATED VOLTAGE	12V DC
POWER CONSUMPTION	6W
MAXIMUM PRESSURE HEAD	2.6M<
MAXIMUM FLOW	500 L/H
MAXIMUM AMBIENT TEMPERATURE	10-50°C
MAXIMUM FLUID TEMPERATURE	10-60°C
POWER CONNECTOR	4PIN PWM FAN CONNECTOR
CABLE LENTH	50CM
TECHNICAL DATA
Reservoir Diameter	60mm
Overall Height	121mm incl. pump
Mounting hole pattern	50x50mm
OPERATIONAL REGIME
PWM DUTY CYCLE	~ 20-100%
DEFULT BEHAVIOR	Runs at 100% duty cycle when no PWM feedback signal is present.
