Ezviz Wire-Free Video Doorbell With Chime Cs-Db2C A0-1E3Wpbr

Introducing the EZVIZ Wire-Free Video Doorbell with Chime (CS-DB2C A0-1E3WPBR), your ultimate solution for home security and convenience. This innovative video doorbell offers a seamless way to monitor your doorstep and interact with visitors from anywhere, thanks to its wireless design and advanced features.

With easy installation and no wiring required, the EZVIZ Wire-Free Video Doorbell ensures hassle-free setup, allowing you to enjoy instant peace of mind. Simply mount the doorbell and connect it to your home Wi-Fi network to start receiving alerts and accessing live video footage on your smartphone or tablet.

Equipped with motion detection technology, the EZVIZ Video Doorbell sends instant alerts to your device whenever motion is detected near your doorstep. You can customize motion zones and sensitivity levels to ensure you only receive notifications for relevant activity, keeping you informed and in control at all times.

The included chime unit extends the functionality of the doorbell, providing audible alerts throughout your home when someone rings the doorbell. With multiple melody options and adjustable volume settings, you can customize the chime to suit your preferences.

Featuring a weatherproof design, the EZVIZ Wire-Free Video Doorbell is built to withstand the elements, ensuring reliable performance year-round. Whether it's rain, snow, or extreme temperatures, you can trust that your home is protected.

Experience the convenience and peace of mind of the EZVIZ Wire-Free Video Doorbell with Chime. Order now and elevate your home security to the next level.

Model Parameters
Model CS-DB2C-A0-1E3WPBR
Camera Parameters
Image Sensor 1/2.7" Progressive Scan CMOS (Supports low light sensitivity)
Lens 2.2 mm@F2.4, Ultra FOV 160° Vertical
Day & Night IR-cut filter with auto-switching
IR Range Max. 6 m (20 ft)
Video Parameters
Max. Resolution 1536 x 1536 FHD
DNR 2D/3D DNR
Video Compression H.265/H.264
Frame Rate Max: 15fps; Self-Adaptive during network transmission
PIR Sensor
Sensing Angle 100°
Sending Distance Max. 5 m (16.4 ft)
Sensitivity User adjustable (High, Medium and Low Sensitivity)
Interface
Audio Input Built-in high-sensitivity microphone
Audio Output Built-in high-power speaker
Reset button Yes
Network Parameters
Intelligent Alarm PIR Person Detection
Tamper Alarm Sound and light anti-dismantling alarm (support alarm to mobile phone)
Video Intercom Long-distance video two way talk
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Wi-Fi Parameters
Wi-Fi Standard IEEE802.11b/g/n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64/128-bit WEP,WPA/WPA2,WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g: 54 Mbps, 11n: 150 Mbps
General
Operation Conditions -10°C to 45°C (14°F to 113°F), Humidity 95% or less (non-condensing)
Ingress Protection Grade No IP Grade
Weight 206 g (0.45 lb)
Size 146 mm x 60 mm x 34 mm (5.75” x 2.36” x 1.34”)
Battery Capacity 5200mAh rechargeable lithium battery
Power Supply DC5V±10%
Power Consumption Max.7.5W
Model / Chime
Size 100 x 54 x 37 mm (3.94” x 2.13” x 1.46”)
Power Supply AC 100 ~ 240V
Wi-Fi Standard IEEE802.11b/g/n
Audio Output 65dB within 3 meters
Storage Supports TF card up to 256 G
Weight 120 g (0.26 lb)
