General

• Dimensions

• 139.7×42.2×33.5 mm (L×W×H)

• Weight

• 179 g

• Number of Microphones

• 3

• Touchscreen

• Size: 2.0 inches
  Resolution: 314×556
  Brightness: 700 nits

• Supported SD Cards

• microSD (up to 512 GB)

• Recommended microSD Cards

• Recommended models:
  SanDisk Extreme Pro 32GB V30 A1 UHS-I Speed Grade 3
  Kingston Canvas Go!Plus 64GB UHS-I Speed Grade 3
  Kingston Canvas Go!Plus 128GB UHS-I Speed Grade 3
  Kingston Canvas React Plus 64GB UHS-II Speed Grade 3
  Kingston Canvas React Plus 128GB UHS-II Speed Grade 3
  Kingston Canvas React Plus 256GB UHS-II Speed Grade 3
  Lexar Pro 256GB SDXC UHS-I V30 R160/W120 (1066x)
  Lexar Pro 512GB SDXC UHS-I V30 R160/W120 (1066x)

Gimbal

• Controllable Range

• Pan: -235° to 58°
  Tilt: -120° to 70°
  Roll: -45° to 45°

• Mechanical Range

• Pan: -240° to 63°
  Tilt: -180° to 98°
  Roll: -220° to 63°

• Max Controllable Speed

• 180.0°/s

• Angular Vibration Range

• ±0.005°

Camera

• Sensor

• 1-inch CMOS

• Lens

• Format Equivalent: 20 mm
  Aperture: f/2.0
  Focus Range: 0.2 m to ∞

• ISO Range

• Photo: 50-6400
  Video: 50-6400
  Low-Light Video: 50-16000
  Slow Motion: 50-6400

• Electronic Shutter Speed

• Photo: 1/8000-1 s
  Video: 1/8000 s to the limit of frames per second

• Max Image Size

• 16:9, 3840×2160
  1:1, 3072×3072

• Zoom

• Digital Zoom
  Photo: 3840×2160, 2x
  Video: 1080p, 4x; 2.7K, 3x; 4K, 2x
  UVC & Livestream: 1080p, 4x
  Slow Motion/Timelapse: Not available

• Still Photography Modes

• Single Shot: Approx. 9.4 MP
  Countdown: Off/3/5/7 s
  Panorama: 180°, 3×3

• Normal Video

• 4K (16:9): 3840×2160@24/25/30/48/50/60fps
  2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
  1080p (16:9): 1920×1080@24/25/30/48/50/60fps
  3K (1:1): 3072×3072@24/25/30/48/50/60fps
  2160p (1:1): 2160×2160@24/25/30/48/50/60fps
  1080p (1:1): 1080×1080@24/25/30/48/50/60fps
  3K (9:16): 1728×3072@24/25/30/48/50/60fps
  2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
  1080p (9:16): 1080×1920@24/25/30/48/50/60fps

• Slow Motion

• 4K (16:9): 3840×2160@120fps
  2.7K: 2688×1512@120fps
  1080p: 1920×1080@120/240fps

• Hyperlapse

• 4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30

• Timelapse

• 4K/2.7K/1080p@25/30fps
  Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
  Duration: 5/10/20/30 mins, 1/2/3/5/∞ hours

• Motionlapse

• 4K/2.7K/1080p@25/30fps
  Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
  Duration: 5/10/20/30 mins, 1/2/3/5 hours
  Supports setting four positions

• Low-Light Video

• 4K (16:9): 3840×2160@24/25/30fps
  1080p: 1920×1080@24/25/30fps

• Max Video Bitrate

• 130 Mbps

• Supported File System

• exFAT

• Photo Format

• JPEG/JPEG+DNG

• Video Format

• MP4 (H.264/HEVC)

• Built-in Storage Capacity

• The camera does not have built-in storage, but storage capacity can be expanded by inserting a microSD card.

• Audio Output

• 48 kHz 16-bit; AAC

Battery

• Type

• LiPo

• Capacity

• 1300 mAh

• Energy

• 10.01 Wh

• Voltage

• 7.70 V

• Operating Temperature

• 0° to 40° C (32° to 104° F)

• Charging Temperature

• 5° to 45° C (41° to 113° F)

• Operating Time

• 166 mins
  ^{Tested at room temperature (25° C/77° F) and 1080p/24fps (16:9), with Wi-Fi off and screen off. This data is for reference only.}

• Charging Time

• 16 mins to 80%; 32 mins to 100%
  ^{Tested in a laboratory environment with the DJI 65W PD charger (sold separately).}

Connection

• Wi-Fi Operating Frequency

• 2.400-2.4835 GHz
  5.150-5.250 GHz
  5.725-5.850 GHz

• Wi-Fi Protocol

• 802.11 a/b/g/n/ac

• Wi-Fi Transmitter Power (EIRP)

• 2.4 GHz:
  < 23 dBm (FCC)
  < 20 dBm (CE/SRRC/MIC)5.1 GHz:
  < 23 dBm (FCC/SRRC)
  < 20 dBm (CE)5.8 GHz:
  < 23 dBm (FCC/SRRC)
  < 14 dBm (CE)

• Bluetooth Operating Frequency

• 2.400-2.4835 GHz

• Bluetooth Transmitter Power (EIRP)

• < 14 dBm

• Bluetooth Protocol

• BLE 5.2, BR/EDR
